Black Annealed Wire Coils - Black Binding Wire, Black Annealed Tie Wire
Annealed Black Wire, or Black Annealed Wire, is also known as Fire Annealed wire, or Burnt Iron Wire, widely used in binding and tying uses. Black annealed wire gets its name from its plain black color. Popular sizes are 8 gauge, 9 gauge, 9.5 gauge, 10 gauge , 11 gauge, 11.5 gauge , 12 gauge, 13 gauge, 14 gauge and more. Diameter ranges from 0.30mm to 4.19mm. Tensile strength ranges from 300 to 450N/mm2. Oxide finish or oil coated. Packed in bundles, rolls / coils big or small, spools, sticks.
Processing
Steel rod - wire drawing - thermal annealing - oiling - coiling.
Wire Drawing: The wire is processed from the Q195 wire rod first by simple drawing process into bare wire. Into various wire gauges.
Annealing: Annealing is intended to return to the wire its ductility which it had lost during drawing. This is the setting process to reduces internal stress and reduces the amount of defects like dislocations. The wire annealing can be carried out in batches (bell-type furnace) or in line (in-line furnace). Different thickness of wire require different temperature. The tensile strength is 400N~600N. Standard coil is10kg, 25kg, 50kg and 100kg.
The wire annealing prepares the iron wire for future production steps. Further processing include milling, wire re-drawing and wire looping, wire bending and fabrications.
Major Products ( Classified according to wire sizes and packing forms)
Black Tie Wire
12g size
Black Annealed quality
Designed for auto tying wire
Packed on tubular, steel carriers
Black Tying Wire
Tying wire
Packed in 25kg coil.
Size: 1.9mm
